DHP 5512098 - Step 13: Drawer Box Construction

19 /32
B34551209801
13
11
13
X 4
X 4X 4
Screw (11) into (F2) & (C2); Insert (12) on both side of (F3).
Attach (F3) & (K2) to (F2) & (C2); Fasten by turning CAM (13) clockwise as far as possible.
13.1
13.2
13.3
F2
C2
F3
F3
F2
C2
K2
12
