EXTERIOR PARTS OF THE EVAPORATIVE COOLER
UNPACKING AND INSTALLING CASTERS
• Keep the evaporative cooler in an upright position and remove the packaging.
• Make sure all the parts are present: Castors (4pcs) & Screws (16pcs), Remote Controller (1pc),
Ice Pack (2 pcs).
• Lay the evaporative cooler on its side gently. Locate screw holes for the casters under the
Reservoir. Use the screws provided to fasten the casters to the underside of the Reservoir. Set the
cooler right-side up when the casters are installed.
(Air Outlet)
