5.1 Climate class and temperature class
The climate class indicated on the rating plate refers to the following values:
CLIMATE CLASS: 5
• 43°C (IEC/EN 60335-2-89)
• 40°C room temperature with 40% relative humidity (EN 16825)
• (IEC/EN ISO 23953)
Safety standard: IEC/EN 60335-2-89 (32°C ± 2°C)
The rating plate contains the product’s identication and technical data. The information it contains is listed below:
** Manufacturer
1. Appliance’s year of manufacture
2. Item Model
3. Production code
4. Serial number
5. Electrical data: supply voltage (V), number of phases (~), supply
frequency (Hz), absorbed current (A) and maximum absorbed power (kW)
6. Climate class
7. Lighting power (W)
8. Type of refrigerant gas
9. Quantity of refrigerant gas (Gr)
10. Degree of protection against dust and water (IP)
11. Drainage heating element power (W)
12. Defrost heating element power (W)
13. Gas insulation
Warning: before installing the appliance, make sure that the electrical connection preparations comply with the information indicated on the rating
plate. It is prohibited to remove or modify the rating plate or any other warning label.
5.2 Interpretation of the model
The model indicated on the plate can be read as follows:
Emainox s.r.l.– Via Pontebbana 9 – 33098 Valvasone PN (Italy)
MOD.
ART.
MATR.
EL
-
V
~
Hz
A
kW
CLIMATIC CLASS
KLIMA KLASS
ILLUMINAZIONE
LIGHTING
W
REFRIGERANTE
REFRIGERANT TYPE
Gr IP
RESISTENZA SCARICO
DISCHARGE RESISTANCE
W
RESISTENZA SBRINAMENTO
DEFROSTING RESISTANCE
W
GAS ISOLAMENTO
INSULATION GAS
MADE
in
ITALY
Emainox s.r.l.– Via Pontebbana 9 – 33098 Valvasone PN (Italy)
2019
MOD.
7BRHC3P1660
ART.
8073117HC
MATR.
EL
220-230
V
1F+N
~
60
Hz
3
A
0,48
kW
CLIMATIC CLASS
KLIMA KLASS
5
ILLUMINAZIONE
LIGHTING
W
REFRIGERANTE
REFRIGERANT TYPE
R290
90
Gr IP
24
RESISTENZA SCARICO
DISCHARGE RESISTANCE
155,0
W
RESISTENZA SBRINAMENTO
DEFROSTING RESISTANCE
W
7 BR HC 3P 16 60 R
1 2 3 4 5 6 7
1 - Depth 4 - Details 6 - Supply frequency
6 600 mm 2C 2 drawers 60 60 Hz
7 700 mm 3C 3 drawers 50 Hz
9 900 mm 4C 4 drawers
6C 6 drawers 7 - Refrigeration
2 - Function 2P 2 doors R Remote group
BR Refrigerated counter 3P 3 doors Group on board
BC Freezer counter
5 - Length
3 - Refrigerant gas 12 1200 mm
HC Gas R290 16 1600 mm
Gas R452A
5.3 Commands and controls
The equipment is controlled by the electrical panel located inside the compressor compartment and by the control panel located in the dashboard.
**
