Diamondback 64684 - Parts List and Diagram; Parts List

Page 21;&(%$*4.8"4,7%<'*#$"&8#=%/7*,#*%4,77%>?@@@?@AA?BCDC1Item 64684
EF;6GHIJ6KFGLIMNFLMG6MFMO6 E6GPJ
J,($ U*#4("/$"&8 i$V
1 Socket Head Cap Screw M10 x 50 4
2 Flat Washer Ø10 8
3 Insert A 4
4 Sleeve 4
5 Water Tray Frame Assembly 1
6 Hose Clamp 2
7 Lock Nut M10 4
8 Pan Head Screw ST4.2 x 13 25
9 Stop Block 2
10 Flat Washer Ø4 4
11 Lock Nut M8 7
12 Front Panel 1
13 Pin Shaft Ø8 x 45 2
15 Handle 2
16 Spring Pin (A) 2
17 Right Rail 1
18 Insert B 4
19 Left Rail 1
20 Toggle Table Stop 1
21 Retaining Plate Block (A) 2
22 Retaining Plate Block (B) 2
23 Side Extension Tray A 1
24 Pan Head Screw ST4.2 x 25 6
25 Bracket 3
26 Pressure Spring (A) 1
27 Socket Head Cap Screw M8 x 80 1
28 Flat Washer Ø8 9
29 Socket Head Cap Screw M8 x 60 8
30 Pan Head Screw M5 x 30 4
31 Front Limit Block 1
32 Lock Nut M5 4
33 Front Limit Block (A) 1
34 Screw Sleeve (A) 1
35 Lock Nut M6 4
36 Screw 4
37 Bearing 608-2RS 9
38 Bearing 688 4
39 Flat End Set Screw M5 x 10 1
40 Pan Head Screw M5 x 12 8
41 Spring Washer Ø5 5
42 Flat Washer Ø5 9
43 Table Stop 2
44 Pan Head Screw M4 x 10 7
45 Table Positioning Block 1
46 Steel Ball Ø6 1
47 Compression Spring 1
48 Roller Screw (B) 1
49 Bearing Screw 6
50 Roller 3
51 Screw 2
52 Retaining Ring 6
53 Bearing Washer (A) 3
54 Flat End Set Screw M5 x 15 2
55 Table Lock Lever 1
56 Extension Table Lock Knob 1
57 Extension Table 1
58 Miter Gauge Assembly 1
J,($ U*#4("/$"&8 i$V
59 Right Large Table Insert 1
60 Right Small Table Insert 1
61 Left SmallTable Insert 1
62 Left Large Table Insert 1
63 Table 1
64 Bearing Screw M8 3
65 Roller 3
66 Miter Gauge Lock Knob 1
67 Spring Washer Ø4 2
68 Flat Washer Ø4 3
69 Miter Base 1
70 Hex Nut M6 1
71 Compression Spring 1
72 Steel Ball Ø8 1
73 Miter Body 1
74 Screw 1
75 Miter Screw M6
76 Miter Lock Lever 1
77 Countersunk Head Screw M6 x 10 1
78 Side Extension Tray B 1
79 Extension Tray B Locking Tab 1
80 Rear Extension Tray Flap 1
81 Rear Extension Tray 1
82 Bevel Seat Assembly 1
83 Torsion Spring Bushing 2
84 Torsion Spring 1
85 Lock Bolt M8 1
86 Bevel Lock Lever Cover 1
87 Compression Spring 1
88 Screw 1
89 Bevel Lock Lever 1
90 Washer 2
91 Depth Knob 1
92 Depth Lock Knob 1
93 Depth Lock Pin 1
94 O-Ring 6 x 1.8 1
95 Thrust Needle Roller Bearing 0821 1
96 Bevel Angle Pointer 1
97 Hex Bolt M6 x 20 2
98 Flat End Set Screw M6 x 10 2
99 Bevel Angle Bracket 1
100 Rotating Shaft 2
101 Nut M6 2
102 Flat End Set Screw M5 x 8 3
103 Motor 1
104 Depth Stop Lock 1
105 Depth Stop 1
106 Pan Head Screw M5 x 25 4
107 Side Splash Guard 1
108 Large Flat Washer Ø5 1
109 Upper Handle 1
110 Rear Splash Guard 1
111 Inner Blade Guard 1
112 Pan Head Screw M5 x 16 12
113 Water Hose Baffle 1
114 Pan Head Screw M4 x 8 4
115 Saw Blade 1
J,($#%T"#$%,89%U",3(,5
J,($#%T"#$
