3.1 Scope of delivery
The following components are included in the bath
tub lifter's scope of delivery (Figure 1):
1 Drive
2 Backrest
1
3 Spindle retainer bolts (2)
4 Lifting scissors
5 Suction feet (4)
6 Drive base
7 Drive base mount
8 Base plate
9 Gliding shoe
10 Sideflaps (2)
11 Seat section
1
12 Charger
13 Jack plug
14 Hand control with curled cable
1
Operating instructions (not shown)
Details in the illustration can differ from the actual
construction.
1
Applied Part
3.2 Accessories
The following accessories are available for the
bath tub lifter (Figure 2):
1 Turntable / transfer aid
2 Turntable
3 Height adapter
4 Sideflap diverter
5 Abductor wedge
3.3 Rating plate
The rating plate (Figure 3) is attached to the bot-
tom side of the seat section (as from (01/2017) to
the rear side of the backrest). The rating plate
shows the following information:
1 Product name
2 Type B applied part
3 WEEE mark
4 Conformity marking
5 Load capacity
6 Rated voltage/rated consumption
7 Degree of protection
8 Production period
9 Total weight
10 Serial number
11 Device designation
12 Duty cycle
13 Notice (refer to the accompanying documents)
14 Manufacturer
15 Sales/service address
3.4 Technical data
Bath tub lifter (Figure 9)
Total weight, excluding hand
control
10.5 kg
XXL: 11.1 kg
Weight, seat unit 6.8 kg
XXL: 7.4 kg
Weight, backrest 3.7 kg
Weight, hand control (ECO) 0.47 kg (0,42 kg)
Seat depth (A) 500 mm
Seat height max. (B) 455 mm
Seat height min. 65 mm
Total depth (backrest upright)
(C)
690 mm
Total depth (backrest lowered) 900 mm
Total height (D) 1105 mm
Height, backrest (E) 680 mm
Width, backrest (F) 350 mm
Seat width with sideflaps (G) 710 mm
Seat width without sideflaps 375 mm
Base plate floor space 530 x 220 mm
Backrest adjustment up to 40°
Load capacity 140 kg
XXL: 170 kg
Degree of protection, drive IP X6
1
Degree of protection, hand
control
IP X7
2
Degree of protection, entire
device
IP X6
1
Operating voltage (ECO) 14.48 V (10,86 V)
Rated current 5 A
Duty cycle 10 % / 2 min –
90 % / 18 min
Battery (ECO) Lithium-ion
14.48 V (10.86 V)
2150 mAh
Charging time from low-
charge indication
approx. 1 h
Sound power level up/down 49/47 dB(A)
1
Protection against water jets
2
Protection against temporary submersion
