Digi-Pas DWL3000XY User Manual

© 2015 DIGIPAS USA LLC. All Rights Reserved.
CHAPTER 1: DEVICE OVERVIEW
Technical Specification
DWL3000XY
Measurement Range
(Single Axis Mode)
0.00° to ± 90.00°
Measurement Range
( 2-Axis Mode)
0.00° to ± 15.00°
Resolution
0.01° (175µm/M) (0.002 in/ft)
Accuracy
± 0.01° at 0.00° ~ ± 10.00° (175µm/M)
(0.002 in/ft) (36 arcsec.)
± 0.03° at other angle
Repeatability
0.01° (175µm/M) (0.002 in/ft)
Cross Axis Error
Negligible (± 0.0025°)
Vibrometer (Relative g)
1.0
Display
Colour TFT LCD
Power Supply *
4 x AAA 1.5V Batteries / USB
Material
PC ABS / Aluminium
Connectivity
USB 2.0 Cable (≤ 5 metre)
Bluetooth (≤30 metre) (Optional)
PC SYNC Software
Basic Edition
Professional Edition (Optional)
Operating Temperature
-10°C to +50°C (Calibrated)
14°F to 122°F (Calibrated)
Dimension (mm)
188 x 62 x 37
Nett Weight (Approx.)
580 gram
User Self Calibration
Yes
Specifications are subject to change without notice.
*Alternative Device power can be obtained from External USB Power Source .
Note:
Product performance to specification are comply with accredited Calibration & Test Providers in USA, Japan, UK and
Germany to conform with NIST, JIS, UKAS & DIN under the International Laboratory Accreditation Cooperation (ILAC)
and American Association for Laboratory Accreditation (A2LA). For more information, please visit
“www.digipas.com”.
