OVERALL VIEW
CHAPTER 1: TECHNICAL SPECIFICATION
1
Measurement Range
(Single Axis)
Measurement Range
(Dual Axis)
Resolution
Accuracy
Repeatability
Measurement Unit
Vibrometer (Relative g)
Display
Power Supply**
Material
PC Software
USB Connectivity
Wireless (Bluetooth)
Operating Temperature
Storage Temperature
Dimension (mm)
Net Weight (Approximate)
User Self Calibration
DWL3500XY
0.000° to ± 20.000°
0.000° to ± 10.000° *
0.001° (18µm/M)
± 0.001° at 0.000° ~ ± 2.000° (18μm/M)
(0.0002 in/ft)
± 0.003° at other angle
0.001° (18µm/M)
Degree, mm/M, inch/feet
2.0
Colour TFT LCD
4x “AAA” 1.5V / USB
PC ABS / Aluminium /Cast Iron
PC Sync Basic
PC Sync Professional (Optional)
USB 2.0 (< 5 metre)
Optional
-10°C to +50°C
-20°C to +70°C
188 x 62 x 37
1.2 kg
Yes
Specifications are subject to change without prior notice.
Note:
* Use in conjunction with Digi-Pas® Angle Adaptor® to avoid Cross Axis region
** Alterative Device power can be obtained from External USB Power Source .
