Troubleshooting System status LEDs
Digi Connect Family and ConnectPort TS Family
148
LED Behaviors
LED
Pin
Header
EM
Integration Kit
Digi Connect EM
Integration Kit
Digi Connect Wi-EM Development Kit
Bottom
right
(yellow)
6 (+)
8 (-)
Blinking: Network data is transmitted or received This LED is
software
programmable
Digi Connect 48 SB and Digi Connect 4/8 SB with switch
