Digi SM-5100 Operation Manual

7
1.Start to use
1.1 assembly the pole（For pole type&Elevated Type）
1st： Please use 4 screw to fix the pole，(For eleavated type,please fix the cable first)
`
Picture 1
2nd：Fix the flashboard first，then use 2 screw to fix the cover(picture 3)，the eleaved type
should be assembled the 5
th
leg
Please pay attention to the cable
flashboard
This cable and aluminium bracket is only for Elevated type

Digi SM-5100 Specifications

General

Brand	Digi
Model	SM-5100
Category	Printer
Language	English
