2G GSM Gateway Lift Introduction
1. INTRODUCTION
Dear Customer,
thanks for purchasing 2G GSM Gateway Lift.
2G GSM Gateway Lift simulates an analog line where the traditional
fixed line is not available or where it is not convenient to take it.
Thanks to 2G GSM Gateway Lift an analog telephone line is always
ready and you can continue to use your traditional communicators
without connecting to the fixed line, saving the costs of the analog
line.
2G GSM Gateway Lift is the ideal solution for emergency systems
installed in lift that must be compliant with EN81.28 regulation.
1.1. PACKAGE CONTENT
• n.12GGSMGatewayLift
• n.1Switchingpowersupply(IN:100-240Vac/50-60Hz/0.5A–OUT12Vdc/1A)
• n.1GSMAntennawitha3meterscable
• n.1Phonecabletoconnectyourcommunicator(1.5meters)
• n.1User'sGuide
1.2. TECHNICAL FEATURES
• GSMModule:GSM/GPRSDual-Band900/1800MHz
• Outputpower:
- Class4(2W)inGSMat900MHz
- Class1(1W)inDCSat1800MHz
• FXSVoiceInterface
• Off-hookACimpedance:600ohm
• On-hooklinevoltage:48VDC
• Off-hooklinepower:25mA
• Dialingtype:Tone(DTMF)
• Ringingvoltage:38VACrms-REN:3
• Voicecall
• OperatingTemperature:from0°Cto+45°C
• Ledindicators
• Back-upbattery
• CEMarkandRohscompliant
1.3. MECHANICAL FEATURES
• 2RJ11Connectors
• Plug-inSIMcard(1,8V-3Vcompatible)
• ExternalGSMantennaonSMA/fconnector
• Dimensions:115x80x45mm
