Chapter 4: SBS 7-Slot Expansion Chassis 19
Example 1, SBS 7-Slot
(Models DD22-1 and 2101-00-2)
Pro Tools 24 MIX/MIXplus System
Power Macintosh G3, G4, or 9500/9600
Example 2, SBS 7-Slot
(Model DD007-R)
Pro Tools 24 System
Power Macintosh Blue & White G3, or G4
SBS model DD007-R does not have a Backplane
Controller slot. It instead has a built-in chassis
controller with a connector on the back of the
expansion chassis.
Chassis cards with multiple audio interfaces:
Slot Card
Slot 1 MIX Core (Interface #1 and #2)
Slot 2 MIX Farm (interface #3 and #4)
Slot 3 MIX Farm (interface #5 and #6)
Backplane
Controller Slot
Chassis Controller Card
Slot 4 MIX I/O (Interface #7 and #8)
Slot 5 DSP Farm (Interface #9)
Slot 6 DSP Farm or SampleCell card
Slot 7 DSP Farm or SampleCell card
The Beige G3 and 9500/9600 are not sup-
ported with SBS model DD007-R.
To use SBS model 2101-00-2 with a G3 or
G4, it must have the IBM 2.1 Bridge Chip.
Chassis cards with multiple audio interfaces:
Slot Card
Slot 1 d24 (Interface #1 and #2)
Slot 2 d24 (Interface #3 and #4)
Slot 3 DSP Farm (Interface #5)
Slot 4 DSP Farm (Interface #6)
Slot 5 DSP Farm (Interface #7)
Slot 6 DSP Farm or SampleCell card
Slot 7 DSP Farm or SampleCell card
The Beige G3 and 9500/9600 are not sup-
ported with SBS model DD007-R.
