Chapter 3: Expansion Chassis 17
Install the chassis controller card:
1 Install the Digidesign Controller card in the
Expansion Slot of the expansion chassis. For
Magma model PCI-13R, this is the slot nearest
the power supply.
2 Attach the other end of the expansion chassis
cable to the controller card.
Installing the Digidesign Cards
Install the Digidesign audio cards:
1 Install the Pro Tools Core card in slot 4 (the
first available slot) of the expansion chassis.
2 Install the remaining cards in successive PCI
card slots in the chassis, according to your
Pro Tools system:
• Pro Tools|HD
• HD Accel
• HD Process
3 Connect all Pro Tools cards with TDM FlexCa-
bles. See “Connecting Pro Tools|HD Cards” on
page 6.
Example 2, Digidesign 13-Slot
Connecting Audio Interfaces
See “Connecting Audio Interfaces” on page 9.
HD-series cards and Pro Tools|24 MIX-se-
ries cards are not compatible, and cannot be
used in the same computer. HD cards can
only be used in Pro Tools|HD-series sys-
tems, and MIX cards can only be used in
Pro Tools|24 MIX-series systems.
Chassis cards with multiple audio interfaces:
Slot Card
Exp. Slot Chassis Controller Card
Bank 1/Slot 4 HD Core (Interface #1 and #2)
Bank 1/Slot 5 HD Accel (interface #3 and #4)
Bank 1/Slot 6 HD Accel (Interface #5 and #6)
Bank 1/Slot 7 HD Accel (Interface #7 and #8)
Bank 1/Slot 8 HD Accel or HD Process
(Interface #9)
Bank 1/Slot 9 HD Accel or HD Process
Bank 2/Slot 4 HD Accel or HD Process
Bank 2/Slot 5 (empty)
Bank 2/Slot 6 (empty)
Bank 2/Slot 7 (empty)
Bank 2/Slot 8 Available for non-bus master card
Bank 2/Slot 9 Available for non-bus master card
Bank 2/Slot 10 Available for non-bus master card
Expanded Systems Guide.book Page 17 Friday, March 26, 2004 6:47 AM
