Digikeijs DR4018 DIGISWITCH User Manual

DR4018 DIGISWITCH (v1.34)
www.digikeijs.com Pagina / page / Seite / page 15
#
CV Definition Range Value
113
Output Configuration 1
0-255 143
114 Output Configuration 2 (For configuration bits see CV113) 0-255 143
115 Output Configuration 3 (For configuration bits see CV113) 0-255 143
116 Output Configuration 4 (For configuration bits see CV113) 0-255 143
117 Output Configuration 5 (For configuration bits see CV113) 0-255 143
118 Output Configuration 6 (For configuration bits see CV113) 0-255 143
119 Output Configuration 7 (For configuration bits see CV113) 0-255 143
120 Output Configuration 8 (For configuration bits see CV113) 0-255 143
121 Output Configuration 9 (For configuration bits see CV113) 0-255 143
122 Output Configuration 10 (For configuration bits see CV113) 0-255 143
123 Output Configuration 11 (For configuration bits see CV113) 0-255 143
124 Output Configuration 12 (For configuration bits see CV113) 0-255 143
125 Output Configuration 13 (For configuration bits see CV113) 0-255 143
126 Output Configuration 14 (For configuration bits see CV113) 0-255 143
127 Output Configuration 15 (For configuration bits see CV113) 0-255 143
128 Output Configuration 16 (For configuration bits see CV113) 0-255 143
131
Signal 1, configuration OUT 1 - 4
If these CVs contain a value equal to 0 all outputs will switch according to the signal rules. The other CVs that normal-
ly control the outputs will be deactivated.
0-5 0
132 Signal 2, configuration OUT 5 - 8 0-5 0
133 Signal 3, configuration OUT 9 - 12 0-5 0
134 Signal 4, configuration OUT 13 - 16 0-5 0
Bit
Function Default
Value
0 - 3
Intensity of the output. Also called dimmer. Where 0 is completely
off and 15 completely on.
15
0-15
4
Fade in and fade out effect. "0" = no fading "1" = fading active.
Fade speed is controlled by CV111
0
16
5
Blink effect. "0" = no blinking "1" = blinking active. Blink rate is
controlled by CV112
0
32
6
Random effect. " 0" = random off " 1" = random active. Combined
with bit 4 (fade) the lights start with a flash, after which they slowly fade
in. Note: The intensity value should be max. 14 for this effect to work.
0 64
7
Pulse length. is set via CV 121 through 128, when combined with
bit 5 the output blinks, but with inverted phase
0
128
Preset Funcon
0 No Signal
1 Dutch (railways)
2 DB_HP (German main signal)
3 DB_VRHP (German front and main signal)
4 DB_VR (German front signal)
5 NMBS (Belgium railways)
