DR4018 DIGISWITCH (v1.34)
www.digikeijs.com Pagina / page / Seite / page 16
Funcon mapping outputs 1 through 16
This table shows you how to connect the dierent outputs on the DR4018 module (1 through 16) to the swit-
ching keys on your control unit. This is useful when you want to switch more than one output at the same me
with one key. If you want to switch more than one output with one funcon key in the same group then add the
values together.
Example 1 (grey): Key 1 should switch outputs 2 and 5 when ON.
You program: CV141 values 2 + 16 = 18.
Example 2 (black): Key 10 should switch ouputs 1 and 15 when ON.
You program: CV195 value 1 and CV196 value 64.
CV
(A)
OUTPUTS GROUP A ( 1 through 8 ) and GROUP B ( 9 through 16 )
Status
CV
(B)
1 | 9 2 | 10 3 | 11 4 | 12 5 | 13 6 | 14 7 | 15 8 | 16
Key 1
ON 141 1 2 4 8 16 32 64 128 142
OFF 144 1 2 4 8 16 32 64 128 145
Key 2
ON 147 1 2 4 8 16 32 64 128 148
OFF 150 1 2 4 8 16 32 64 128 151
Key 3
ON 153 1 2 4 8 16 32 64 128 154
OFF 156 1 2 4 8 16 32 64 128 157
Key 4
ON 159 1 2 4 8 16 32 64 128 160
OFF 162 1 2 4 8 16 23 64 128 163
Key 5
ON 165 1 2 4 8 16 32 64 128 166
OFF 168 1 2 4 8 16 32 64 128 169
Key 6
ON 171 1 2 4 8 16 32 64 128 172
OFF 174 1 2 4 8 16 32 64 128 175
Key 7
ON 177 1 2 4 8 16 32 64 128 178
OFF 180 1 2 4 8 16 32 64 128 181
Key 8
ON 183 1 2 4 8 16 32 64 128 184
OFF 186 1 2 4 8 16 32 64 128 187
Key 9
ON 189 1 2 4 8 16 32 64 128 190
OFF 192 1 2 4 8 16 32 64 128 193
Key 10
ON 195 1 2 4 8 16 32 64 128 196
OFF 198 1 2 4 8 16 32 64 128 199
Key 11
ON 201 1 2 4 8 16 32 64 128 202
OFF 204 1 2 4 8 16 32 64 128 205
Key 12
ON 207 1 2 4 8 16 32 64 128 208
OFF 210 1 2 4 8 16 32 64 128 211
Key 13
ON 213 1 2 4 8 16 32 64 128 214
OFF 216 1 2 4 8 16 32 64 128 217
Key 14
ON 219 1 2 4 8 16 32 64 128 220
OFF 222 1 2 4 8 16 32 64 128 223
Key 15
ON 225 1 2 4 8 16 32 64 128 226
OFF 228 1 2 4 8 16 32 64 128 229
Key 16
ON 231 1 2 4 8 16 32 64 128 232
OFF 234 1 2 4 8 16 32 64 128 235
* The RED numbers are the standard factory sengs for GROUP A (1 through 8)
* The ORANGE numbers are the standard factory sengs for GROUP B ( 9 through 16 )
