prevent short circuits that can occur if a user accidentally drives a signal that is supposed to be used as an input.
The downside to this added protection is that these resistors can limit the maximum switching speed of the data
signals.
Pmod JA
Pmod Type
Standard
Pin 1
J2
Pin 2
H2
Pin 3
H4
Pin 4
F3
Pin 7
H3
Pin 8
H1
Pin 9
G1
Pin 10
F4
Table 8.1. PLTW S7 Pmod Pinout.
