ZYBO™ FPGA Board Reference Manual
Copyright Digilent, Inc. All rights reserved.
Other product and company names mentioned may be trademarks of their respective owners.
There are many aspects of the Zynq AP SoC architecture that are beyond the scope of this document. For a
complete and thorough description, refer to the Zynq Technical Reference Manual, available at www.xilinx.com.
Figure 3 depicts the external components connected to the MIO pins of the ZYBO. The Zynq Board Definition File
found on the Digilent ZYBO product page can be imported into EDK and Vivado Designs to properly configure the
PS to work with these peripherals.
