LED Mark Status Description
Power PWR
On The device is powered up.
Off The device is powered down.
Registration PON
On The device is registered to PON system.
Off Device is not registered to PON system.
Blink Device is registering.
Optical
signal
LOS
Blink Device does not receive optical signal.
Off Device has received optical signal.
WAN WAN
On WAN connection is up.
Blink Data passing WAN connection.
Off WAN connection is down.
Ethernet
LAN1
LAN2
On Port is connected properly.
Off
Port connection exception or not
connected.
Blink Port is sending or/and receiving data.
Wireless
2.4G
5G
On Wi-Fi is turned on.
Off Device is power off or Wi-Fi is turned off.
Blink
Wi-Fi turned on and with ongoing data
transmission.
Pots PHONE
On
Device has registered to soft-
switch, but without ongoing data
transmission.
off
Device is power off or not registered
to soft-switch.
Blink
The port is with ongoing data
transmission.
Table 1 Panel Lights
