Wireless IP camera User Manual
4 Appendix
4-1 Specification
Type DG-SC1600W DG-SC3600W
Sensor ¼” CMOS Sensor
Lens 3.6mm, Fixed Lens
Min Illumination 0.5Lux 0.3Lux
IR Array 1PCS 4PCS
IR distance Up to 5m Up to 10m
IR-Cut Filter Yes
Video Compression H.264
Max Resolution 1280 X 720 (1MP)
Audio Support Yes; Built-in Mic/ Speaker
Protocol TCP/ IP, UDP, SMTP, DHCP, UPnP
Wireless LAN 802.11b/g/n
Local Storage Micro SD slot (Up to 64GB)
Event Management Events triggered by Motion Detection, Record Video/ Images to
Micro SD via Yoosee utility
Operating Temperature 0degC~+50degC
Operating Humidity 20%~80%, Non-Condensing
Power Rating 5V, 1A (USB Adapter) 5V, 2A
Casing Plastic
