1-5 Camera Hardware Overview
1) DG-SC1600W
A) Front View B) Rear View
---------------------------------------------------------------------------------------
2) DG-SC3600W
A) Front View B) Rear View
* On DG-SC3600W, reset hole is located on the bottom side of IP camera.
Camera Lens
1PCS IR Array
Bracket
MIC
Antenna
Camera Lens
MIC
4PCS IR Array
LED Indicator
Reset Button
Micro SD Slot
Power connector
LAN
Micro SD Slot
