Technology Parameter
Technical Parameter
1.INPUT CHANNEL
GAIN -40dB +6dB
EQUALIZER
EQ TYPE PEQ Low-Shelf High-Shelf All-Pass
EQ FREQUENCY RANGE:[19.7Hz 20.2KHz]
EQ GAIN -12.0dB +12.0dB step.0.5dB
EQ Q VALUE 0.4 128
2.OUTPUT CHANNEL:
SIGNAL INPUT SELECTION OFF,InA,InB,InC,InA+B,InA+C,InB+C,InAll
GAIN -40dB +6dB
EQUALIZER
EQ TYPE PEQ Low-Shelf High-Shelf All-Pass
EQ FREQUENCY RANGE:[19.7Hz 20.2KHz]
EQ GAIN -12.0dB +12.0dB step:0.5dB
EQ Q VALUE 0.4 128
HIGH PASS
HPF 10.0Hz 16KHz
HP SLOPE FLAT THRU,6dB But 12dB/Q=0.5,12dB/Q=0.6,
12dB/Q=0.7,12dB/Q=0.8,12dB/Q=0.9,12dB/Q=1.0,12dB/Q=1.1,
12dB/Q=1.2,12dB/Q=1.3,12dB/Q=1.4,12dB/Q=1.5,12dB/Q=1.6,
12dB/Q=1.7,12dB/Q=1.8,12dB/Q=1.9,12dB/Q=2.0 12dB Bessel,
12dB Butterworth,18dB Butterworth,18dB Bessel,
24dB Butterworth,24dB Bessel,24dB Link-Rily,48dB Butterworth,
48dB Bessel,48dB Link-Rily
LOW PASS
LPF 35Hz 20.2KHz
LP SLOPE SAME AS HPF
COMPRESSION
LIMIT THRESHOLD -40dBu +10dBu,OFF DEFAULT OFF
ATTACK TIME 100 1000dB/s
HOLD TIME 100 1000ms
RELEASE TIME 100 1000dB/s
DELAY 0.00ms 8.00ms 0.00m 2.75m 0.00ft 9.01ft
PHASE 0,180
POWER AC 90V 250V 18VA 50Hz/60Hz
FUSE T1AL/250VAC
SIZE 482mm 158mm 45mm
WEIGHT 2.1Kg(NET WEIGHT)
