1. Parameter setting in input channel.
1.1 GAIN & MUTE:press [MUTE] to adjust MUTE or cancel MUTE.
Turn the small rotatory button to adjust the GAIN.
1.2 EQ:Press [TYPE] or [FILTER NO] to enter EQ menu. Press [FILTER NO]
to shift EQ. Press [CH-] [CH+] to shift channel.
Type:Press [TYPE] to shift EQ type:PEQ Low-Shelf High-Shelf All-Pass.
NOTE:EQ type shift only can be operated when EQ and GAIN is 0dB,Otherwise,
the LCD will return to current screen after display a caution.
Freq: turn [FREQ] in PEQ FILTER to adjust EQ frequency, turn [FAST/EDIT]
to adjust fastly.
Gain:turn [GAIN] in PEQ FILTER to adjust EQ gain,it's unavailable while EQ type
is All-Pass.
Q:turn [Q] in PEQ FILTER to adjust EQ Q value, it's unavailable while EQ type
is HIGH-SHELF LOW-SHELF.
2. Parameter setting in output channel.
2.1 GAIN & MUTE: press [MUTE] to adjust MUTE or cancel MUTE.
Turn the small rotatory button to adjust the GAIN.
2.2 Limit:press [LIMIT] to enter/quit LIMIT set,meanwhile the indicator light up/off
press[PUSH/ENTER] to shift Limit Threshold Limit
Attack Time Limit Hold Time Limit Release Time turn the small rotatory
button to adjust parameter value.
2.3 Delay:press [DELAY] to enter/quit Delay set, meanwhile the indicator light up/off
turn the small rotatory button to adjust parameter value.
2.4 Phase:press [PHASE] to enter/quit Phase set, meanwhile the indicator light up/off
turn the small rotatory button to adjust parameter value.
2.5 HPF & LPF:press [HPF/LPF] to enter HPF set, press[HPF/LPF] again to shift HPF
and LPF. Turn [FREQ] in CROSSOVER to adjust HPF and LPF frequency, turn
[SLOPE] in crossover to adjust HPF and LPF slope.
2.6 EQ:Operational means same as Parameter setting in input channel.
3.
3.1 Store
[STORE] . , .
.
Function operation
Press to enter program store menu If the program locked show as Fig 1
and then reture to main menu
Operation Instruction
OPERA TION
Program sector
locked
Fig 1
5
