DIGISYNTHETIC DSP4800 - Control Panel; Front Panel

CONTROLPANEL
A.FRONTPANEL
1.CHA:AdjustthevolumeofchannelA
2.CHB:AdjustthevolumeofchannelB
3.INPUTINTERFACETOPC
4.OUTPUTINTERFACETOPC
6.POWER:ON/OFF
Note:Presstherotaryencoder(1,2)toswitchbetweentheCHA/Band
CHC/D.
5.220LCDDISPLAYWITHBACKLIT
CHA/C:AdjustthevolumeofchannelA/C(onlyforDSP4800&DSP4800E)
CHB/D:AdjustthevolumeofchannelB/D(onlyforDSP4800&DSP4800E)
