Digital Projection E-Vision Laser 7500 Series Important Information

Digital Projection E-Vision Laser 7500 & 8500 Series
Rev D January 2017
Page 22
Important Information
17
DISPLAYPORT / R / numeric
input 4
Select DisplayPort input.
18
HD-T / G / numeric input 5
Select the HDBaseT input.
19
3GSDI / B / numeric input 6
Select the 3G-SDI input.
20
VGA / 3D / numeric input 7
Select the VGA input.
Use with ALT to toggle the 3D
Format setting between Off and
Auto.
21
COMP1 / EYE / numeric input 8
Select the Component 1 input.
Use with ALT to switch between left
and right eye 3D dominance.
22
COMP2 / PIP / numeric input 9
Select the Component 2 input.
23
ADDR / ALL
Assign and unassign an IR remote
address.
To assign an address:
1. Press and hold this button
until the indicator starts
ashing.
2. Release this button and while
the indicator is still ashing,
enter a two-digit address
using the numeric input
buttons. The indicator will
ash three times quickly to
conrm the change.
To unassign an address and
return to the default address 00,
• Press and hold ALT and this
button simultaneously until the
indicator ashes to conrm
the change.
Pic Mute
OFF
ON
MENU
EXIT INFO
HDMI1
OK
OFF ON
ALT
LENS
FOCUS ZOOM
IN
OUT
IN
OUT
SHIFT
21 3
HDMI2 DVI
DISPLAYPORT HD-T 3GSDI
VGA COMP1 COMP2
BRI
TEST
CON GAMMA
R G B ALL
3D EYE PIP SWAP
4 5 6
7 8 9 0
ALT
ADDR
OSD
OFF
ON
DEFAULT
FREEZE
RE-SYNC
A B C D
USER PRESET
21
18
19
17
20
21
22
