Specifications
Power Supply (Vcc): Operating Range: 9 to 16 V
Range of device constant: k = 500 pulses/km to 99999 pulses/km
Resolution of device constant: 1 pulse/km
Range of time tariff: 0.1 s/unit to 6553.5 s/unit or 0.01 s/unit to 655.35 s/unit
Resolution of time tariff: 0.1 s/unit or 0.01 s/unit
Range of distance tariff: 0.1 m/unit to 6553.5 m/unit or 0.01 m/unit to 655.35 m/unit
Resolution of distance tariff: 0.1 m/unit or 0.01 m/unit
Odometer Transducer Input:
input range: 0 to 16 V
level for LOW voltage: 0 V - 0.3 V
level for HIGH input: 6 V to Vcc
maximum frequency: 7 KHz (with k=99999)
high voltage trigger: high - low transition
Passenger Sensor:
Input range: 0 to 12 V
maximum level for LOW input: 1.4 V
Taxi Light Output:
Maximum Current: 2 A
Output Voltage: Vcc
Lights Outputs:
Maximum Current: 1 A
Output Voltage: Vcc
Printer Power Out:
Maximum Current: direct from Vcc input
Output Voltage: Vcc
RS-232 serial ports: Standard COM1, COM2
