INTRODUCTION:
FEATURES:
• HDMI 1.4b, HDCP 1.4 and DVI 1.0 compliant
• Support video resolution up to 4k2k@30Hz YUV 4:4:4
• The maximum transmission distance via a single CAT6 cable (not included) is
as follows: CAT6: 70m for 1080p, 40m for 4K
• HDMI Pass-Through
• HDCP & 3D Support
• EDID Data Transmission
• Infrared Extender
This product can achieve up to 70m transmission distance while still supporting
up to 1080p 60Hz signals or 40m transmission distance while still supporting up
to 4K 30Hz signals. Features EDID management, which allows and encourages
source and display “handshake” for seamless integration. With only one CAT6
cable (not included), high definition sources with HDMI outputs can be connected
to 4K displays with HDMI inputs over long distances. Deep colour video, DTS-HD
or Dolby TrueHD audio is supported and compatible with the extender. In addition,
the extender is also equipped with bi-directional IR pass-through which allows for
source or display control.
The extender includes two units: transmitting unit and receiving unit. The
transmitting unit is used to capture the HDMI input with IR signals and carries
the signals via one CAT6 cable (not included). The receiving unit is responsible for
equalizing the transmitted HDMI signal and reconstructing IR control signals. The
extender offers the most convenient solution for HDMI extension over a single CAT6
with long distance capability, and is the perfect solution for any application.
SAFETY:
1. Do not open or repair the device without professional assistance to avoid
electrical shock.
2. Do not expose this unit to water, moisture or any liquid.
3. Position the unit in a well ventilated area to prevent the unit from overheating.
4. Only use the supplied DC 12V/1A power adaptor. If you use any third party
power supplies, ensure the voltage is the same to prevent the unit from damage.
