Section - 3 Effects and Parameters
This section provides you with a detailed description of the Digital effects in the S-100 and their parameters and values. A
complete list of these effects is also printed on the top of the S-100.
The Modulation effects menu offers a vast list of modulating effects ranging from Chorus to a Rotary Speaker simulator.
These modulation effects are ideal producing lush sounding effects that can add dimension to any signal. The parameters
and values for the modulation effects are as follows:
Speed The Speed parameter controls the speed of the modulation in the effect.
Range is from 0 to 99 or Slow to Fast.
Depth This parameter controls the amount of depth of the modulation effect.
Range is from 0 to 40.
Delay This parameter controls the delay time within the modulation effect.
Range is from 0 to 40 milliseconds.
Feedback This parameter controls the amount of regeneration feedback in the
modulation effect. Range is from 0 to 97%.
Type This parameter selects between six different modulation extremes.
Cross-over Frequency This parameter selects the frequency where the signal is split between
the Rotor and the Horn. Settings are 1 - 4
Level This parameter allows you to set the overall level of the selected effect.
Range is from 0 to 99.
Modulation Effects
Effect Name
Parameter 1
Parameter 2 Parameter 3
Parameter 4
Chorus - CH
Flange - FL
Phaser - PH
Tremolo - tr
Panner - Pn
Rotary Speaker - RS
Speed - SP
Speed - SP
Speed - SP
Speed - SP
Speed - Sp
Type - Ty
Depth - de
Depth - de
Depth - de
Depth - de
Depth - de
Speed - SP
X-over Freq - CF
Delay - dL
Feedback - Fb
Feedback - Fb
N/A
N/A
Level - L
Level - L
Level - L
Level - L
Level - L
Level - L
S-100
User Guide
13
Section -3 Effects and Parameters
