DigiTech xc4132 - 3 Product Specification

4
3
3
Product Specification
l Serial Port
l RS-485/422
● No. of Ports : 422/485 x 1 Port (Terminal Block)
● RS-422 Signals : RxD+ , RxD- , TxD+ , TxD- in Full-duplex
(Surge Protection)
● RS-485 Signals : Data+ , Data- in Half-duplex (Surge Protection)
● Receive buffer : 576 Byte
● Transmit buffer : 640 Byte
● Baud Rate Speed : 300 bps!230.4k bps
● Built-in RS-422/RS-485 Terminal Resister (Surge Protection)
● Connected Serial port type identification : Auto-Detection
● Built in Terminal 100 Ohm Terminal resistor SW selection ON/OFF
● 15KV ESD for all signal
l USB Port
No. of Ports: USB x 1 Port
● Chipset : Silicon Laboratories CP2102
● Fully compatible with the USB V1.0, V1.1, V2.0
● USB type A connector
● Baud Rates: Full speed 12 Mbps.
