7
Camera Connections
DIGITUS
®
outdoor Plug&View cameras are equipped with a special
cable.
Check installation option by means of the installation illustration.
Reset button:
Press and hold this button
for 10 seconds after the
camera is connected and
ready-to-use. This resets
the camera to default
settings.
Network cable:
Connect the network
cable to you router on the
network to establish
Internet connection.
DC 12V power
connection:
Connect the external
power adapter to supply
the camera with power.
LED status indicator:
The blue LED status
indicator shows if the
camera is supplied with
power.
For DN-16039, DN-16043 and DN-16048, its power can be supplied
directly to the camera via the network cable in connection with a
PoE injector or PoE switch.
