4
1000Base-T: UTP category 5e, 6 cable
(maximum 100m)
1000Base-SX: 62.5μm/50μm
MMF(2m~550m)
1000Base-LX: 62.5μm/50μm
MMF(2m~550m) Or
Transfer Method Store-and-Forward
MAC Address Table 8K
Switching Capacity 52Gbps
Packet Forwarding Rate 38.688Mpps
Packet Buffer 4.1Mbit
Jumbo Frame 9216Bytes
Working
Mode
Enable Flow Control and all ports can
communicate with each other
control
Disable Flow Control and all ports can
communicate with each other
VLAN mode
Port 1~24 cannot communicate with each
other, but can communicate with the
PoE Ports (RJ45) 24x PoE ports compliant with 802.3at/af
Power Pin Assignment 1/2(+),3/6(-)
PoE Budget 370W
LED
indicators
Per Device Power: Green
Per Port Link/Act, PoE
Power Supply 100~240VAC,50/60HZ,400W
Power Consumption Maximum (PoE on):421.2W(220V/50Hz)
