Digitus DS-12860 User Manual

10
Chapter 4
Keyboard operation
Overview
The KVM product in this desktop series offers a large number of easy hotkey
operations, making it easy to set up KVM via the keyboard or to complete port
switching.
Hotkey setting:
This series of products provides 4 combinations of hotkeys for user selection and
setting. The default hotkey is “LEFT” [ CTL ] [ CTL ] to switch to the next online port,
[ CTL ] + [ SHIFT ] [ 1 ] or [ 2 ] Switch to the specified port. The following table is a
description of the four hotkey combinations, please check the settings when using
the user:
1. [ CTL ] + [ SHIFT ] mode
Hotkey combination
Description
【 CTL 】【 CTL 】
Press twice to switch to the next device
online port
【CTL 】+【 SHIFT】【1】or【2】
Switch to the computer corresponding
to the port of [ 1 ] [ 2 ]
[ CTL
】
+ [ SHIFT
】
[→] or [ ↓ ]
Switch to the next computer
[ CTL
】
+ [ SHIFT
】
[ ←] or [ ↑ ]
Switch to the previous computer
【
CTL
】
+
【
SHIFT
】【
B
】
Buzzer on or off
【 CTL 】 + 【 SHIFT 】【 S 】
Automatic switching mode, the default
is 5seconds, press [ ESC ] to exit
【CTL 】+【 SHIFT 】【S】【N】
Set the automatic switching mode
interval, press [ ESC ] to exit
【 CTL 】+【 SHIFT】【 SCROLL 】
Switch to [ SCROLL ] + [ SCROLL ]
hotkey combination mode
【CTL 】+ 【 SHIFT 】 [ NUM 】
Switch to [ NUM ] + [ NUM ] hotkey
combination mode
【 CTL 】+【 SHIFT 】【 CAPS 】
Switch to [ CAPS ] + [ CAPS ] hotkey
combination mode

Digitus DS-12860 Specifications

General

DC-in jack	Yes
HDMI version	1.4b
Console ports	USB A
USB connector type	USB Type-A, USB Type-B
HDMI ports quantity	6
Number of computers controlled	2
Video bandwidth	30 Hz
Maximum resolution	3840 x 2160 pixels
Cables included	HDMI, KVM
Product color	Black
Rack mounting	No
LED indicators	Status
Housing material	Metal
Storage temperature (T-T)	-20 - 60 °C
Operating temperature (T-T)	0 - 80 °C
Operating relative humidity (H-H)	0 - 80 %
Country of origin	China
Harmonized System (HS) code	85176200

Weight and Dimensions

Depth	92 mm
Width	132 mm
Height	66 mm
Weight	575 g
