Digitus DS-43308 User Manual

6
RS232 Serial command
For correct communication, set the RS232 parameters to the following setting:
Baudrate: 9600
Parity: None
Data Bits: 8
Stop Bits: 1
RS232 control
1) It supports RS232 control to select the input and output channel,
the baud rate is 9600, and the connector is a 9-pin port.
2) Use the serial port software, please set COM firstly, and then correspond
to the following figure in the various channel commands.
Instruction list
HDMI output
HDMI input 1
HDMI input 2
HDMI input 3
HDMI input 4
HDMI output1
PS11R
PS12R
PS13R
PS14R
HDMI output2
PS21R
PS22R
PS23R
PS24R
HDMI output3
PS31R
PS32R
PS33R
PS34R
HDMI output4
PS41R
PS42R
PS43R
PS44R
HDMI output1
PA1R PA2R PA3R PA4R
HDMI output2
HDMI output3
HDMI output4
Change all
output/input states
PAP1P2P3P4R,
Output 1 selects signal source P1
Output 2 selects signal source P2
Output 3 selects signal source P3
Output 4 selects signal source P4
Gets the current
output / input state
PA?R
Command return
All of the above commands, if they were sent successfully,
the output status will be returned accordingly
For example, send command “PA? R”
Return OK+
1
2
2
4
output 4 selects input 4
output 3 selects input 2
output 2 selects input 2
output 1 selects input 1
If the command is wrong, return “err”
