FAQ
Q: No video/audio signal output on the displays?
A: 1) Please check and make sure the Matrix Switch is connected well
and powered.
2) Please check and make sure all HDMI cables are connected well
3) Please check and make sure the input channel of displays are correct.
Q: Picture quality is not fluent and stable?
A: 1) Please check and make sure all HDMI cables are connected well.
2) Try to connect the source device to display device directly, or change to
another source device for a try to see the picture quality.
3) Please use high quality HDMI 2.0 standard cable when HDMI 4Kx2K
signal input.
Specification
Items
Specification
HDMI Signal
HDMI 2.0, Full compatible with HDCP 2.2
Inputs
4 HDMI
Outputs
4 HDMI
Transmission rate
18Gbps
Support resolution
480i@60Hz, 480p@60Hz, 576i@50Hz, 576p@50Hz,
720p@50/60Hz, 1080i@50/60Hz; 1080p@50/60Hz,
3840x2160@25/30/60Hz
Support audio format
DTS-HD/Dolby-true HD/LPCM7.1/DTS/Dolby-AC3/DSD
YUV
4:4:4
Video signal
0.5~1.5Vp-p(TM DS)
DDC signal
5Vp-p(TTL)
Video bandwidth
600MHz
HDMI port
Type A 19 pin, female
RS232
9 Pin serial port seat
Working temperature
0° ~ 60°C
Power supply
DC12V/2A
Power consumption
20W (Max)
Product dimension
429.8 (L) x 170.7 (W) x28 (H) mm
Weight
1.65 Kg
Color
Black

Digitus DS-43308 Specifications

General

Brand	Digitus
Model	DS-43308
Category	Matrix Switcher
Language	English
