Dillenger C965 - Table of Contents

2
Contents
Details 3
Features 4
LCD Instructions 5
Functional Description 6
Basic Parameter Settings 9
Password Parameter Settings 11
Error Code Denitions 18
Assembly Instructions 19
Assistance Level Instructions 21
Contact Us 22
Electrical Parameters
- 24V/36V/48V battery supply
- Rated operating current : 10mA
- Max operating current : 30mA
- O leakage current < 1uA
- Max output current to controller : 50mA
- Operating temperature : -20 °C to 70 °C
- Storage temperature : -30 °C to 80 °C
Dimensions & Material
Product shell is ABS, transparent window is made with high strength Acrylic, the stiness
equals tempered glass.
Dimensions
L90mm*W54mm*H13.3mm
