Dilog DL9110 - RCD Trip Current (Ramp) Tests

DL9110 / DL9118 Operating Instructions
- 27 -
10mA
30mA
100mA
300mA
500mA
Please note that the DL9110 / DL9118 is not capable of performing all
of the different test currents for all of the different manual RCD settings.
10mA 30mA 100mA 300mA 500mA
½ I∆N





1 I∆N





5 I∆N



5.12 RCD trip current (Ramp) Tests
The DL9110 / DL9118 will only allow the Earth Loop
Impedance test to be performed if the correct voltages
are detected between phase-neutral (PN illuminated),
phase-earth (PE illuminated) and neutral-earth (NE not
illuminated).
Leakage currents in the circuit following the residual
current protection device may influence the
measurement.
Note: The DL9110 / DL9118 will determine the fault voltage that
may appear on the protective conductor during the test. If
the fault voltage is greater than 25V the DL9110 / DL9118 will
indicate >25V on the LCD, but the user may proceed with the
test. If the fault voltage is great than 50V, this is indicated on
the LCD and the test is inhibited.
F1 F2 F3 F4
0
o
/ 180
o
AC/DC/Selective
Not used Test current
0
o
/ 180
o
(F1)
Use the F1 key to alternate between the starting angle of the current.
All RCD tests will start on zero crossing.
