OPU-1
UNIVERSAL POWER-LINE CARRIER SYSTEM TYPE OPU-1
GENERAL DESCRIPTION - Rev 7 (May 2019)
➢ Digital channel (OFDM/OQAM): 32 kHz at
324 kbit/s (maximum), in each direction for
adjacent bands.
16 kHz at 160 kbit/s, in each direction for
adjacent bands.
8 kHz at 72 kbit/s, in each direction for
adjacent bands.
4 kHz at 32 kbit/s, in each direction for
adjacent bands.
See examples in FIGURE 13.
The possibilities can be enlarged with the use
of the additional filters
FIGURE 13 Transmission capacity examples
NOTE: The OPU-1 can work with different line filters, depending on the backplane type.
