E-10
English
12
12 Technical Data
1 Type and order code
AWP 30HLW
2Design
with additional internal heat exchanger
2.1 Casing Painted sheet steel
2.2 Colour White, similar to RAL 9003
2.3 Nominal cylinder volume l 290
2.4 Cylinder material Enamelled steel according to DIN 4753
2.5 Nominal cylinder pressure bar 10
3Model
3.1 Dimensions W x H x D (overall) mm 660 x 700 x 1700
3.2 Weight kg Approx. 175
3.3 Electrical connection (plug-in - lead length approx. 2.7 m) 1/N/PE ~ 230 V, 50 Hz
3.4 Fuse A 16
3.5 Refrigerant / total filling weight - / kg R134a / 1.0
4 Operating conditions
4.1 Selectable water temperature (heat pump operation
±1.5 K
) °C
23 to 60
4.2 Air temperature operating range of heat pumps
1
°C
1. At temperatures below 8 °C (+/- 1.5 °C) the heating element switches on automatically and the heat pump module switches off automatically; the switch-back value of the controller
is 3 K
8 to 35
4.3 Sound pressure level
2
dB(A)
2. At a distance of 1 m (free-standing installation without inlet and outlet ducting or without 90° pipe bends on the outlet side)
53
4.4 Air flow during heating-only heat pump operation m
3
/h
450
4.5 External compression Pa 100
4.6 Maximum length of pipe that can be used for the air duct m 10
5 Connections
5.1 Diameter of the air duct connection (inlet/outlet) mm 160
5.2 Transfer area of the internal tube heat exchanger m
2
1.45
5.3 Sensor pipe D
internal
(for sensor – heat exchanger operation) mm
12
5.4 Water connections - cold water / hot water R 1“
5.5 Circulation pipe R 3/4"
5.6 Heat exchanger flow / return flow R 1“
6 Performance data
6.1 Mean power consumption
3
at 60 °C W
3. Heating up of the nominal volume from 15 °C to 60 °C at an air inlet temperature of 15 °C and 70 % relat. humidity
615
6.2 Mean heat output
4
at 45 °C W
4. Heating up of the nominal volume from 15 °C to 45 °C at an air inlet temperature of 15 °C and 70 % relat. humidity
1870
6.3 COP
(t)
according to EN 255 at 45 °C -
3.5
6.4 Stand-by energy consumption at 45 °C/24h (W) 47
6.5 Max. mixed water volume at 40 °C V
max.
l
290
6.6 Heating-up period from 15 °C to 60 °Ct
h
h
9.1
