6
Installation.
Mounting of the unit
This unit is a PORTABLE AIR CONDITIONER. It can be moved from room to room, so
the cooling can follow you anywhere.The mounting is easy, beneath a window or wall.
Please refer to either of the following ways -
1. Using the foam strips
• Connect the supplied foam
strips with the exhaust pipe,
let the hot air flow to the
outside.
• Should the foam strip(s) be
too large, cut off the extra
part to fit the window.
1. Adaptor - for insertion over hose and
into back of the air conditioner.
2. Adaptor - for insertion over hose and
into foam strip.
3. Exhaust hose.
4. Foam strip - for filling the open
window space and with hole for
connection to exhaust hose.
5. Foam strip - for filling the open
window space.
6. Round window connector.
7. Cap for round window connector.
8. Water tray.
Accessories.
1
2
3
4
5
6
7
8
