Dimplex DXMBCF User Manual

Remote Control
The remote control comes complete with a CR2025 3V battery
tted. To replace the battery simply remove the securing screw,
unclip and remove the battery cover on the back and replace the
battery, then carefully ret the cover on the back and replace the
battery, then carefully ret the cover, snap into place and ret the
securing screw.
Specication Details - DXMBCF Symbol Value Unit
Maximum Fan Flow Rate F 9.2 m³/min
Fan Power Input P 32.3 W
Service Value SV 0.3 (m³/min)/W
Standby Power Comsumption PSB 0.64 W
Fan Sound Power Level LWA 64 dB(A)
Maximum Air Velocity c 4.1 meters/sec
Rated Voltage V 220-240 V
Rated Frequency Hz 50 Hz
Measurement Standard for Service
Value
IEC 60879:1986
Technical Specication

Dimplex DXMBCF Specifications

General

Brand	Dimplex
Model	DXMBCF
Category	Fan
Language	English
