Ordering Codes
DOEE
054722
Voltage / Current
Input Voltage Range
100V to 265V AC, 50/60Hz
Voltage Accuracy
+/- 1%
Voltage Resolution
0.1 Volt
Current Measurement Range
0.1 to 80A
Current Accuracy
1.6A~4A +/-1.5% 4A~ 80A +/-1%
Current Resolution
0.01A
kWh, PF, kVAh
kWh Accuracy
+/- 1%
kWh Resolution
0.01 kWh
Power Factor Accuracy
+/- 1%
Power Factor Resolution
0.01
kVAh Accuracy
+/- 1%
kVAh Resolution
0.01 kVAh
Certification
Certification
CE
Metering Standard
Class 1 (Accuracy only)
Wireless Technology
Radio Technology
Dimplex GFSK
Radio Frequency
868 MHz ISM Band
Channels
4 Channels (1 - 4)
Max Tx Power
+13dBm
Rx Sensitivity

-105dBm@25Kbps
Data Rate
up to 25 kbits/sec
Wireless Range
Indoor Range
up to 50m
Outdoor Range
up to 300m (direct line of sight)
Serial Technology
Standard
Modbus RTU
Range
up to 200m
Physical
Dimensions (LxWxH)
231 x 125 x 48mm
Weight
0.201 kg
Mounting
Wall Mounting Flanges
Enclosure
V0 Polycarbonate
Operating Temperature
-20°C to +45°C
Operating Humidity
up to 85% (non-condensing)
Rated Input Power Power Consumption
1 Watt
