Dimplex Free-E - Page 34

µ ¶ · · ¸ ¹ º º » ¼ º ½ ¾ ¿ À Á ¹ Â Ã Ä ¿ Å ¹ ¶ Æ ¿ À ¼ ¿ Ç Ä ¿ È Ã Ç À É º ½ Ê Ë Â Ì Í Ê º Ã À É Î Ï Ð Ñ Å Ò
Ó Ô Õ Õ Ô Ö × Ø Ù Ô Ö
Ç ¶ Ì Í · ¿ Ú Û Ü º Û ½ » Ý Ä Ç Ü Ä ¹ º ½ Í Û Ü º Û ½ »
Þ ß
à á â ã ä ä å æ ç è é â ê ë å ì í æ è ì î ï ð ä å ì è ñ ì î ò è ó æ ô ê õ ö å å ê ÷




Ordering Codes
DOMM
054739
Voltage / Current
Input Voltage Range
215V to 255Vac, 50/60Hz
Maximum continuous AC output current at 210 V
14.2A +/-1%
Maximum continuous AC output current at 230 V
13.0A +/-1%
Maximum continuous AC output current at 254 V
11.8A +/-1%
Maximum output over current protection
16A +/-1%
Maximum input overvoltage protection
260 Vac
Electrical
Cooling concept
Forced air convection
Relay output ratings
16A…... 250Vac
Range of output power factor
0.9x … 1.0
Nominal Power factor
0.99
External Input voltage range
24 - 230Vac
Peak Free-E efficiency
98.2%
General Purpose I/O
Configurable inputs / outputs
1 PSU 5Vdc ……1A
1 Digital input/output
1 Isolated input 24Vac..240Vac
2 Analog inputs/outputs
Wireless Technology
Radio Technology
Dimplex GFSK
Radio Frequency
868 MHz ISM Band
Channels
4 Channels (1 - 4)
Max Tx Power
+13dBm
Rx Sensitivity

-105dBm@25Kbps
WiFi
IEEE 802.11 b/g/n
Wireless Range
Indoor Range
up to 50m
Outdoor Range
up to 300m (direct line of sight)
Serial Technology
Standard
Modbus RTU
Range
up to 200m
Standby power
Power Consumption
10 Watt
Physical
Dimensions (LxWxH)
316 x 279 x 110 mm
Weight
kg
Mounting
Wall Mounting Flanges
Enclosure
V0 Polycarbonate
Operating Temperature
-20°C to +45°C
Operating Humidity
up to 85% (non-condensing)
Certifications
CE
Fully EMC compliant
