INSTALLING DRAINAGE PVC HOSE
When using the function of continuous drainage, the PVC hose must be placed horizontally
below the drainage hole. Must avoid uneven ground and folding the hose.
CONTINUOUS DRAINAGE FEATURE
Drain hose
Back of the unit
Drain cover
- 4 -
1. To save having to periodically empty the water
tank, this unit can be configured for continuous
drainage. You can use a PVC drain hose
to connect to the continuous drainage connector.
2. Unscrew and remove the drain cover at the rear
of the unit.
3. Remove the soft rubber stopper. Put it into the
water tank for safe keeping.
4. Insert the drain hose through the hole of the
drain cover.
5. Connect the drain hose to the drain port.
6. Tighten the drain cover in clockwise direction
onto the rear of the unit.
7. Place the bucket on its original location.
Drain cover
Drain cover
Soft rubber
stopper
Drain cover
Drain hose
Drain cover
Drain hose
Drain hose
Bucket
Drainage hose is not included with this unit
