Dimplex LI 1422C - Integration Diagram; Hydraulic Integration Diagrams

EN-28 452170.66.01-EN · FD 0303 www.dimplex.de
English LI 1422C - 1826C
15 Integration diagram
15.1 Hydraulic integration diagrams
NOTE
º
ºººº
The hydraulic integration diagram is an example and intended only as an aid. The system requires professional and safety-
approved layout by a specialist planner. All information in the section on installation and the corresponding safety notes must be
observed at all times.
R2.2
N1
E10.1
