12
The heater controls can be easily adjusted by using the six buttons on the User
Interface.
1. The Home Screen shows the options available at each stage of adjustment.
Here the current target room temperature is displayed along with the
mode of operation. Any use of the Advance function will be displayed
here, and pressing Enter will show the functions which are enabled.
The currently active mode of operation is displayed at the top of the screen
e.g. ‘Manual’ or ‘Out All Day’ timer.
When the heater is in a timer profile and trying to achieve or maintain a room temperature, ‘Heating On’ wil be
displayed, otherwise, ‘Heating O’ will be displayed. The words ‘Heating On / O’ will not be displayed in a manual
mode of operation.
When the controller buttons have not been pressed for a long period of time, the display will ‘sleep’ and the text
will disappear. The heater is still on and active in whatever Mode it was set to.
2. Menu - Displays the Main Menu;
- Boost – Activate Boost Mode
- Mode - Set the mode of operation.
- Settings – Time/Date, Temperature units etc.
3. Back returns to the previous screen.
4. The Up and Down buttons are used to navigate through the menus and adjust the required room temperature
on the main screen. The screen colour changes based on the temperature selected, showing deep blue through
to bright red.
5. Enter is used to enter sub menus and to confirm actions.
6. The Advance button is only used when a Timer Mode is active, it allows the timer schedule to be changed
temporarily by forcing a ‘Heating On’ period to begin or end early.
User Timer
21
°
C
Heating ON
