Dimplex PLXE Series User Manual

17
ADVANCE
MENU
BACK
ENTER
Timer Mode
User Timer
Home All Day
Out All Day
Away
ADVANCE
MENU
BACK
ENTER
Return
Date/Time
Saturday
31-2-18
07:00
21
°
C
ADVANCE
MENU
BACK
ENTER
Return
Date/Time
Away Set
ADVANCE
MENU
BACK
ENTER
Away
21
°
C
Until
31-02-18
07:00
NOTE:
The Back button can be used to
end the Away Mode countdown
early.
Continuous Heat Modes
A continuous heat mode is eectively a constant Heating On period. The Heater will remain in a continuous heat
mode indefinitely until the mode is changed by the User.
Available Continuous Heat Modes
Each continuous heat mode starts with a default Target Temperature value.
• Manual
• Default 21°C
• Can be changed from the Home Screen to any value within the Heater’s Temperature Range.
• Eco
• Default 19°C
• Can be changed from the Home Screen to any value in the Heater’s minimum temperature range (8-18°C)
• Frost Protection
• Default 7°C
• Not User Definable
ADVANCE
MENU
BACK
ENTER
Modes
Timer Mode
Manual Mode
Eco Mode
Frost Protect
ADVANCE
MENU
BACK
ENTER
Manual
21
°
C
ADVANCE
MENU
BACK
ENTER
User Timer
21
°
C
Heating ON
ADVANCE
MENU
BACK
ENTER
Main Menu
Boost
Modes
Settings
To select a continuous heat mode, first press the Menu button. Use the arrow
keys to highlight ‘Modes’ and press the Enter button. From here, use the arrow
keys to highlight the desired continuous heat mode and press Enter to select.
You will then be returned to the home screen in your chosen mode.

Dimplex PLXE Series Specifications

General

Type	Electric Panel Heater
Color	White
Installation	Wall Mounted
IP Rating	IP24
Frost Protection	Yes
Frequency	50Hz
Warranty	2 Years
Power Output	0.5kW, 0.75kW, 1.0kW, 1.5kW, 2.0kW
Safety Features	Overheat Protection
Voltage	230V
Thermostat	Electronic
Dimensions	Varies by model
Weight	Varies by model
