Dimplex PLXE Series User Manual

6
All Models
Controls
Digitally controlled, Electronic Thermostat accurate to (±0.2°C)
Timer modes:
7 Day Programmable User Timer, Out All Day, Home All Day,
Continuous heat modes:
Eco, Manual, Frost Protect, Runback
Additional Modes:
Away, Boost, Setback
Controller UI
• Graphical display with RGB backlight
• Capacitive buttons with audio feedback
• User replaceable battery (Coin-Type)
• Open window detection, Adaptive-start, Advance time period
• Wide SP range (7-30°C)
• Bluetooth for software updates
• Child Lock & Heater Lock (PIN-based)
Construction
• Durable epoxy-polyester powder coated steel casing with louvered forward facing grille
• Advanced controls with capacitive sense technology for total flexibility of heating
*Note: PLXC300E features a slotted grille
Element Compact, finned, mineral filled sheathed element
Installation • H-frame wall bracket
Safety
• Thermal cut-out. Auto reset type
• Overheat detection
IP Rating IP24
Battery 3V coin cell battery to backup real time clock. Battery life >5 years.
Supply
1.3 metres fitted, 3 core for fused spur installation, 1/N/PE ~230-240 V, 50Hz
Class I, with earth wire
Colour / Finish Metal Chassis, Air Outlet Grille & Control Moulding - Trac White (RAL 9016)
Approvals CE, BEAB
Guarantee 2 years
Country of Origin United Kingdom
Manufacturer
Glen Dimplex Heating & Ventilation
(GDC Group Ltd.)

Dimplex PLXE Series Specifications

General

Type	Electric Panel Heater
Color	White
Installation	Wall Mounted
IP Rating	IP24
Frost Protection	Yes
Frequency	50Hz
Warranty	2 Years
Power Output	0.5kW, 0.75kW, 1.0kW, 1.5kW, 2.0kW
Safety Features	Overheat Protection
Voltage	230V
Thermostat	Electronic
Dimensions	Varies by model
Weight	Varies by model
