13
To install a 120 V wall switch:
1. Pull out the 5 wires marked L1, L2,
N, NH, and G (black, red, white,
blue, and green).
2. Connect the N (white) and the NH
(blue) wires from the built-in electric
firebox to the N (white) from the
power supply panel.
3. Terminate L2 (red) with a wire
connector (not included).
4. Connect L1 (black) from the built-in
electric firebox to the L1 (black) from
the main power wall switch using a
wire connector (not supplied).
5. Connect the other end of L1 (black)
to the L1 terminal of the main power
wall switch.
6. Connect G (green) from the built-
in electric firebox to the G (green)
ground wire of the main power wall
switch by using a wire connector
(not supplied).
Electrical
7. Secure the two remaining ground
wires (green) with a ground screw in
the main switch wall box.
8. Insert all the wiring of the main
power wall switch into the main
switch wall box.
9. Insert all the wiring back into the
built-in electric firebox and secure
with a cable clamp.
10. Makes sure all connections are
tight.
