DINGLI JCPT0607DCS - Specifications

OPERATOR’S MANUAL with Maintenance Information
Specifications
11
JCPT0607DCS
Height, working maximum 5.6 m
Height, platform maximum 3.6 m
Height, stowed maximum
Rails up
2.03 m
Height, stowed maximum
Rails lowered
1.67 m
Width 0.76 m
Length, platform retracted 1.44 m
Length, platform extended 2.04 m
Platform dimensions
Platform length × width
1.29×0.7 m
Platform extension length 0.6 m
Maximum load capacity 240 kg
Maximum wind speed 12.5 m/s
Wheelbase 1.05 m
Turning radius (outside) 1.55 m
Turning radius (inside) 0.4 m
Ground clearance 6 cm
Ground clearance
Pothole guards deployed
1.5cm
Weight 880kg
Machine weights vary with option configurations
Power source 2 Batteries , 12V 85Ah
Controls Proportional
AC outlet in platform Standard
Maximum hydraulic pressure
(functions)
155 bar
System voltage 24 V
Tire size Φ230×80 mm
Airborne noise emissions <70 dB
Maximum sound level at normal operating
workstations (A-weighted)
Vibration value does not exceed 2.5m/s
2
Maximum slope rating,
Stowed position
25%
Maximum side slope rating,
Stowed position
25%
Note: Slope rating is subject to ground
conditions and adequate traction.
Maximum working slope X-1.5°,Y-3°
Drive speeds
Stowed, maximum 4.0 km/h
Platform raised, maximum 1.1 km/h
Floor loading information
Tire load, maximum 450 kg
Tire contact pressure 10.9 kg/cm
2
1068.2 kPa
Occupied floor pressure 1143.3 kg/m
2
11.2 kPa
Note: Floor loading information is approximate
and does not incorporate different option
configurations. It should be used only with
ade
q
uate safet
y
factors.
Continuous improvement of our products is a
DINGLI policy. Product specifications are
subject to change without notice or obligation
