DINGLI JCPT1523DC - Legend

OPERATOR’S MANUAL with Maintenance Information
Legend
8
Legend
2
3
4
5
6
7
8
9
10
11
12
13
14
15
16
1
1 Lanyard anchorage point
9 Outrigger housing
2 Platform extension lock handle
10 Outrigger footpads
3 Platform entry gate
11 Steer tire
4 Platform controls
12 Entry ladder
5 Platform guard rails
13 Batteries tray(behind cover)
6 Manual storage containers
14 Non-steer tires
7 Platform extensions
15 Ground controls
8 Hydraulic tanks (behind cover)
16 Safety arm (hidden from view)
