OPERATOR’S MANUAL with Maintenance Information
Specifications
15
Model JCPT1823DC
Height, working maximum
18m
Height, platform maximum
16m
Height, stowed maximum
Rails up
3.19m
Height, stowed maximum
Rails folded
2.49m
Width, standard tires
2.29m
Length, platform retracted
Models with one extension deck
3.94m
Length, platform extended
Models with one extension deck
5.4m
Length, platform retracted
Models with two extension decks
3.98m
Length, platform extended
Models with two extension decks
6.6m
Length, platform retracted
Models with outriggers
4.88m
Platform dimensions
Platform length × width
3.98m×1.83m
Platform extension length
1.43m, 1.16m
Maximum load capacity
680kg
Maximum wind speed
12.5m/s
Wheelbase
2.86m
Turning radius (outside)
5.2m
Turning radius (inside)
2.04m
Ground clearance
30cm
Power source
375AH
System voltage
48V
Weight
See Serial Label
Machine weights vary with option configurations
Controls
Proportional
AC outlet in platform
Standard
Maximum hydraulic pressure
(functions)
240bar
Tire size - standard tires
33×12-20
Airborne noise emissions
<80dB
Maximum sound level at normal operating
workstations (A-weighted)
Gradeability
40%
Maximum working slope
X-2°,Y-3°
Drive speeds
Stowed, maximum
5.0km/h
Platform raised, maximum
1.0km/h
Floor loading information
Tire load, maximum
3030kg
Outrigger load, maximum
(if equipped)
3030kg
Tire contact pressure
9.0kg/cm
2
884.8kPa
Occupied floor pressure
1033.8kg/m
2
10.1kPa
Note: Floor loading information is approximate
and does not incorporate different option
configurations. It should be used only with
adequate safety factors.
Continuous improvement of our products is a
policy. Product specifications are subject to
change without notice or obligation.
