Grill Assembly
Some Early Machines Were Released With Different Grill.
These Machines Can Be Retrotted With The Current Style
Item Qty Dingo Part No Description
1 1 K94078 Grill Bottom
2 1 K94079 Grill Top
3 2 K94084 Grill Nylon Washer
4 4 131-211-002 Plain Washer 1/4” x 1/2”
5 2 122-121-000 Nyloc Nut M6
6 2 111-211-025 Hex Bolt M6 x 25
7 2 100-000-053 Spring Pin Ø1/8” x 3/4”
8 4 131-131-000 Plain Washer M8
9 4 111-311-016 Hex Bolt M8 x 16
